Specification
| Model No | Asus Rog Zephyrus M16 Gaming Laptop |
| Part No | 90NR0BW1-M002J0 |
| Color | Off Black |
| Processor | 13th Gen Intel® Core™ i9-13900H Processor 2.6 GHz (24M Cache, up to 5.4 GHz, 14 cores: 6 P-cores and 8 E-cores) |
| Memory | 16GB DDR5-4800 SO-DIMM (2 x 8GB) |
| Storage | 1TB PCIe® 4.0 NVMe™ M.2 SSD |
| Display | ROG Nebula HDR Display : 16-inch QHD 16:10 (2560 x 1600, WQXGA) Mini LED Anti-glare display DCI-P3 : 100% Refresh Rate : 240Hz Response Time : 3ms G-Sync Pantone Validated MUX Switch NVIDIA® Advanced Optimus Support Dolby Vision HDR : Yes |
| Graphics | NVIDIA® GeForce RTX™ 4070 Laptop GPU ROG Boost: 2030MHz* at 140W (1980MHz Boost Clock 50MHz OC, 115W 25W Dynamic Boost, 115W 25W in Manual Mode) 8GB GDDR6 |
| Operating System | Windows 11 Home |
| Lighting | Aura Sync |
| Input & Output | 1x 3.5mm Combo Audio Jack 1x HDMI 2.1 FRL 2x USB 3.2 Gen 2 Type-A 1x USB 3.2 Gen 2 Type-C support DisplayPort™ / power delivery 1x Thunderbolt™ 4 support DisplayPort™ / power delivery |
| Camera | 1080P FHD IR Camera for Windows Hello |
| Connectivity | Wi-Fi 6E(802.11ax) (Triple band) 2*2 Bluetooth® 5.3 Wireless Card (*Bluetooth® version may change with OS version different.) |
| Audio | Smart Amp Technology Dolby Atmos AI noise-canceling technology Hi-Res certification Built-in 3-microphone array 2x 2W Tweeter 2x 2W dual-force woofer with Smart Amp Technology |
| Keyboard and Touchpad | Backlit Chiclet Keyboard 1-Zone RGB Touchpad |
| Battery | 90WHrs, 4S1P, 4-cell Li-ion |
| Power Supply | ø6.0, 280W AC Adapter, Output: 20V DC, 14A, 280W, Input: 100~240C AC 50/60Hz universal TYPE-C, 100W AC Adapter, Output: 20V DC, 5A, 100W, Input: 100~240V AC 50/60Hz universal |
| Security | BIOS Administrator Password and User Password Protection Kensington Security Slot™ Trusted Platform Module (Firmware TPM) |
| Dimensions (W x D x H) | 35.5 x 24.6 x 2.11 ~ 2.29 cm (13.98" x 9.69" x 0.83" ~ 0.90") |
| Weight | 2.30 Kg (5.07 lbs) |
| Package Content | Laptop, Power Adapter, user manual |
| Warranty | 1 Year ( As per Manufacturer Policy ) |
